[Scouter] Springboot와 Scouter 연동하기

• Scouter 정보
  • Scouter 버전 : 2.15.0
• Java Application 정보
  • Java 11
  • Springboot 2.6.5
• 기타 정보
  • 사용 Port : 6100
  • 스카우터 설치 디렉터리 : /application/scouter

---

스카우터 다운로드

• 스카우터 다운로드

    cd /application
    wget https://github.com/scouter-project/scouter/releases/download/v2.15.0/scouter-all-2.15.0.tar.gz
    tar -zxvf scouter-all-2.15.0.tar.gz

---

스카우터 서버

• 설정정보 /application/scouter/server/conf/scouter.conf

    # Server
    server_id=demo-collector-server

    # Network
    net_udp_listen_port=6100
    net_tcp_listen_port=6100

    # Dir
    db_dir=/application/scouter/server/database
    log_dir=/application/scouter/server/logs

    # Log
    log_rotation_enabled=true

    # Compress
    compress_xlog_enabled=true
    compress_profile_enabled=true

    # Manager
    mgr_purge_enabled=false

• 기동 스크립트/application/scouter/server/startup.sh

• 중지 스트립트 /application/scouter/server/stop.sh

---

스카우터 호스트 에이전트

• 설정정보 /application/scouter/agent.host/conf/scouter.conf

    # Network
    net_collector_ip=127.0.0.1
    net_collector_udp_port=6100
    net_collector_tcp_port=6100

    # Object
    obj_name=demo-app-server

    # Alert
    disk_alert_enabled=true
    disk_warning_pct=80
    disk_fatal_pct=90

    cpu_alert_enabled=true
    cpu_warning_pct=80
    cpu_fatal_pct=90

    mem_alert_enabled=true
    mem_warning_pct=80
    mem_fatal_pct=90

• 기동 스크립트 /application/scouter/agent.host/host.sh

• 중지 스크립트 /application/scouter/agent.host/stop.sh

---

스카우트 자바 에이전트

• 설정정보 /application/scouter/agent.java/conf/spring-scouter.conf

    # Network
    net_collector_ip=127.0.0.1
    net_collector_udp_port=6100
    net_collector_tcp_port=6100

    # Object
    obj_host_name=demo-app-server
    obj_name=demo-springboot-app

    # Trace
    trace_interservice_enabled=true
    trace_http_client_ip_header_key=X-Forwarded-For

• 기동 명령

    nohup java -javaagent:/application/scouter/agent.java/scouter.agent.jar \
    -DScouter.config=/application/scouter/agent.java/conf/springboot-scouter.conf \
    -Dobj_host_name=demo-app-server \
    -Dobj_name=demo-springboot-app \
    -jar /application/springboot-scouter-0.0.1-SNAPSHOT.jar 2>&1 &

• 중지 명령

    kill -15 `ps -ef | grep java | grep Dobj_name=demo-springboot-app | awk '{print $2}'`

---

• 참고

  Scouter APM 소소한 시리즈 #1 - 설치하기

  scouter/Configuration.md at master · scouter-project/scouter

  scouter/Setup.md at master · scouter-project/scouter
